Primarily designed to start or stop flow, ANA Gate Valve is usually left fully open or completely closed creating a flow with less resistance when fully open. This feature of gate valve results in active flow of water.


Code : NewANA-GV104
Type : Full Bore
Material : Forged Brass
Pressure Resistance : 200 PSI (16 Bar)

Characteristics & Performance
100% free of corrosion with quality handle made from aluminum alloy.   Anti Blow Out System and One Piece Design is applied for the prevention of seepage problems.
ANA valve offers an unobstructed waterway when widely open and acts as resistant device when shutoff.   Full bore type creating greater endurance as well as performance.
Design wise for easier use of handle, in which each handle is designed for best suit of finger curve.



Application
1. Stops water flow from flooding in case of piping leakage.
2. Capable for various installations on pipeline or between the front and back of water meter, pump, tank, etc.
3. Typically use in general pumping system, suitable for common house, building construction, and general industry.
4. Flow-control is impractical as it best serves fully open and close functions.
Size (PF)
Pcs / Box
Pcs / Carton
1/2"
10
40
3/4"
8
32
1"
6
24
1 1/4"
4
16
1 1/2"
3
12
2"
2
8
2 1/2"
1
6
3"
1
6
4"
-
2
